Leadwell VE Series Machining Center
Leadwell Machining Center2 models
LEADWELL is a leader in VMC machines from Taiwan that are very innovative and of high quality in the international market place. Our VE Series is the best VMC machine that LEADWELL manufactures which is a precision machining center designed particularly for the toolroom, die-mould shop and manufacturing purposes. Our machines are known for their excellent after sales services and environmentally-friendly machine tools.
Model Comparison
| Specification | V-22iF/iR | V-30iF/iR |
|---|---|---|
| Table Size(mm) | 600x400 | 860x450 |
| Travel X/Y/Z(mm) | 510x420x510 | 800x400x510 |
| Job Weight on Table(kg) | 250 | 300 |
| Distance between spindle & Table (Min- Max)(mm) | 100-610 | 600-610 |
| Spindle Type | BT-40, Belt /Direct drive | BT-40, Belt /Direct drive |
| Spindle (rpm) | 10,000/12,000 & 15,000 opt. | 10,000/12,000 & 15,000 opt. |
| Spindle Power(kw) | 11 | 11 |
| Machine Size (LxWxH)(mm) | 2440x2117x2370 | 2130x2400x2370 |
| Machine Weight(kg) | 3380 | 3500 |
Features & Accessories
High Rigidity:
- FEA Analysis
- High rigidity structure design
- 3 Axis ball screw prestressing
High Reliability:
- Roller type motion system
- 3 Axis absolute motor
High Efficiency:
- V-32A.V-42A.V-52A with high torque spindle motor
- Rapid feed rate 48/48/36mm
- Spindle speed 12,000rpm(optional)
- Tool change time T to T 1.8sec
- Tool change time C to C 4sec
High Flexibility:
- 30 tools magazine available
- 4/5 axis rotary table available
- Front/Rear Chip Disposal available
