A highly rigid Leadwell NV Series Vertical Machining Center featuring a one-piece saddle and roller-type motion system. This efficient CNC VMC Machine supports up to 1800 kg table loads, delivering exact tolerances and massive ROI for buyers needing a Heavy Duty Vertical Machining Center.
LEADWELL

Leadwell NV Series Machining Center

Leadwell Machining Center4 models

The Leadwell NV Series of Machining centers are designed for large-scale heavy-duty machining of large and difficult-to-machining parts. Being a Taiwan manufactured series of high-rigidity VMCs, the Leadwell NV Series are specifically tailored for parts manufacturing facilities requiring accurate machining of precise tolerances without any sacrifice in speed. All the machines are supported by ATPL’s world-class after sales support.

Get a QuoteSpare Parts

Model Comparison

SpecificationV-40iLV-50LV-60iV-80i
Table Size(mm)1120x6101420x6101550x7502100x1000
Travel X/Y/Z(mm)1020x635x6101270x635x6101520x800x7202040/1000/720
Job Weight on Table(kg)800100012001800
Distance between spindle & Table (Min- Max)(mm)100-710100-710120-840120-840
Spindle TypeBT-40, Belt /Direct driveBT-40, Belt /Direct driveBT-40, Belt /Direct driveBT-40, Belt /Direct drive
Spindle (rpm)10,000/12,000 & 15,000 opt.10,000/12,000 & 15,000 opt.10,000/12,000 & 15,000 opt.10,000/12,000 & 15,000 opt.
Spindle Power(kw)18.518.51515
Machine Size (LxWxH)(mm)3200x2200x27213810x2200x27213942x4017x33485464x4512x3335
Machine Weight(kg)620070001050015100

Features & Accessories

High Rigidity:

  • FEA Analysis
  • High rigidity structure design
  • Dual nuts ball screw deiwgn in X and Y axis
  • The new wider base and saddle improved machine rigidity
  • Saddle one piece design

High Reliability:

  • Roller type motion system
  • 3 Axis absolute motor
  • One piece telescope design in rear Y axis
  • Ball screw bearing lubrication system design
  • Front chip disposal system with surrounding coolant system

High Efficiency:

  • Rapid feed rate 48mm
  • Spindle speed 12,000/15,000 rpm(optional)
  • Tool change time T to T 1.8sec
  • Tool change time C to C 4sec

High Flexibility:

  • 30 tools magazine available
  • 4/5 axis rotary table available
