A highly versatile PRECILASER Crane Type Mould Laser Welding Machines setup available in up to 600W power. This heavy duty laser welding machine features a flexible overhead arm for repairing oversized dies, ensuring zero thermal distortion and excellent ROI for industrial mold repair.
PRECILASER

Crane Type Mould Laser Welding Machine

Mould Laser Welding2 models

Crane type mold laser welding machines are available in two power options: 200W and 400W. Crane type mold laser welding machines can provide customers with not only laser processing equipment but also comprehensive processing solutions, including integration with fiber laser cutting machines for complete and efficient production lines.

Get a QuoteSpare Parts

Model Comparison

SpecificationPL200WPL400W
Average laser power200W400W
Max laser power240W440W
Max energy of single pulse75J120J
Power Consumption≤ 6 KW12KW
Laser wavelength1064nm1064nm
Pulse width0.5-20ms0.5-20ms
Laser welding frequency0.5 -100HZ0.5 -100HZ
Spot size range0.2-2mm0.2-2mm
Dia. of Welding wire0.1-0.8mm0.1-0.8mm
Dimensional1000mm x 600mm x 1500mm1000mm x 600mm x 1500mm
Weight≤ 300kg≤ 300kg
Power Supply415VAC ± 10% / 50-60HZ415VAC ± 10% / 50-60HZ
Size of the worktable500mm X 300mm X 900mm (L x W x H)500mm X 300mm X 900mm (L x W x H)
Travel of the worktable170mm X 130mm X 200mm (L x W x H)170mm X 130mm X 200mm (L x W x H)
Load-bearing of worktableless than 100KGless than 100KG
Travel of the laser tube200mm X 900mm X 650mm (L x W x H)200mm X 900mm X 650mm (L x W x H)

Features & Accessories

Advantages:

  1. High accuracy , the welding spot diameter is 0.2mm-0.5mm
  2. Little affect area , no distortion of the processing parts.
  3. No effect for etch after welding , low oxidation rate ,the color of the processing parts is intact.
  4. No stomata or sand hole disappeared after welding.
  5. Can process at the welding point , especially applicable to repairing mound requiring polishing.
  6. The processing parts can reach 50-60 rockwell hardness.

Applicable to material & fields:

Repair cracks , collapsed horn , touched edge and damaged sealing side, welding on horniness material (~HRC60)

Additional Information:

  • Port of Dispatch: Exworks Noida, UP, India
  • Delivery Time: 4 to 6 weeks
  • Packaging Details: Wooden Box
